Linear Actuators

Motor Type: Brush
Rated Voltage: 12V / 24V
Max Load: 6,000N
Max Speed: 28mm/s
Max Stroke: 600mm
Limit Switches: Internal
Feedback: Optional Hall Sensor

Motor Type:Brush
Rated Voltage: 24V
Max Load: 6,000N
Max Speed: 75mm/s
Max Stroke: 650mm
Limit Switches: Internal
Feedback: None

Motor Type: Brush
Rated Voltage: 12 ~ 48VDC
Max Load: 7,000N
Max Speed: 35mm/s
Max Stroke: 1,000mm
Limit Switches: Internal
Position Feedback Available: Endstop Signal, Hall Sensor, Reed Switches

Electro Hydraulic Linear Actuator
Motor Type: Brush
Rated Voltage: 12 ~ 48VDC
Max Load: 8,000N
Max Speed: 16mm/s
Max Stroke: 350mm

Motor Type: Brushed / Brushless
Rated Voltage: 220 ~ 380VAC / 24 ~ 48VDC
Max Load: 8,000N
Max Speed: 74mm/s
Max Stroke: 800mm
Limit Switches: External
Synchronization Capability: Up to 5 Motors

Motor Type: Brush
Rated Voltage: 12 ~ 48VDC
Max Load: 10,000N
Max Speed: 35mm/s
Max Stroke: 1,000mm
Limit Switches: Internal
Position Feedback Available: Endstop Signal, Hall Sensor, Potentiometer, Reed Switches

Motor Type: Brush
Rated Voltage: 12 ~ 48VDC
Max Load: 12,000N
Max Speed: 38mm/s
Max Stroke: 1,000mm
Limit Switches: Internal
Position Feedback Available: Endstop Signal, Hall Sensor, Potentiometer, Reed Switches

Motor Type: Brush
Rated Voltage: 12 ~ 48VDC
Max Load: 12,000N
Max Speed: 37mm/s
Max Stroke: 1,000mm
Limit Switches: Internal
Position Feedback Available: Hall Sensor, Potentiometer, Reed Switches

Motor Type: Brush
Rated Voltage: 12 ~ 48VDC
Max Load: 12,000N
Max Speed: 28mm/s
Max Stroke: 1,000mm
Limit Switches: Internal
Feedback: Optional Endstop Signal, Hall Sensor, Potentiometer, Reed Switches

Motor Type: Brush
Rated Voltage: 12V / 24V
Max Load: 17,000N
Max Speed: 28mm/s
Max Stroke: 1,000mm
Limit Switches: Internal
Feedback: Optional Hall Sensor

Motor Type: Brushed / Brushless
Rated Voltage: 220 ~ 380VAC / 24 ~ 48VDC
Max Load: 20,000N
Max Speed: 100mm/s
Max Stroke: 1,000mm
Limit Switches: Internal
Synchronization Capability: Up to 4 Motors
