- Motor Voltage: 12V / 24V
- ø50mm Actuator Body
- Max. Load: 5,000N
- Min. Installation Dimensions: Lmin = S+315
- Built-in Limit Switch
- Optional Hall Feedback, Optional Limit Switch Output Signal
- Noise: ≤56dB, Protection: IP65
- Color Option: Silver or Black
Part Number Configurator
| Series | Stroke | Voltage | Code | Color | ||||
|---|---|---|---|---|---|---|---|---|
| ML50 | - | S1000 | - | 24 | - | A | - | B |
Performance
| Code | A | B | C |
|---|---|---|---|
| Push Rated Load (N / lbf) | 1,500 / 337.25 | 3,000 / 674.50 | 5,000 / 1,124 |
| Pull Rated Load (N / lbf) | 1,350 / 303.50 | 2,700 / 607 | 4,500 / 1,011.50 |
| No Load Speed (mm/s) +/- 10% | 9.0 | 5.0 | 2.5 |
| Full Load Speed (mm/s) +/- 10% | 7.5 | 4.0 | 2.0 |
| 12VDC No Load Current (A) | 1.0 | 1.0 | 1.0 |
| 12VDC Full Load Current (A) | 3.0 | 3.5 | 3.5 |
| 24VDC No Load Current (A) | 0.6 | 0.6 | 0.6 |
| 24VDC Full Load Current (A) | 2.0 | 2.5 | 2.5 |
Dimensions
Unit: mm
Downloads
Catalog Download: ML Series Actuator Catalog.pdf
