- 12 ~ 48VDC Motor
- Up to 7,000N Dynamic Load
- Clutch Overload Protection
- Position Feedback Available: Endstop Signal, Hall Sensor, Reed Switches
- Maximum Stroke: 1,000mm
- Protection Level: IP65
- Noise Level: ≤65 dB
- Color: Black
Specifications
| Code | Max. Dynamic Load (N) | Max. Self-Locking Load (N) | Pitch (mm) | Max. No Load Speed (mm/s) +/- 10% | Max. Full Load Speed (mm/s) +/- 10% |
|---|---|---|---|---|---|
| A | 7,000 | 10,000 | 3.17 | 5.5 | 4.0 |
| B | 7,000 | 10,000 | 5.0 | 8.5 | 7.0 |
| C | 5,000 | 8,000 | 3.17 | 11.0 | 9.5 |
| D | 4,000 | 7,000 | 5.0 | 17.0 | 14.0 |
| E | 3,000 | 5,000 | 3.17 | 22.0 | 18.0 |
| F | 2,000 | 4,000 | 5.0 | 35.0 | 28.5 |
Dimensions
Unit: mm
Performance
