- 12 ~ 48VDC Motor
- Up to 17,000N Dynamic Load
- Electronic Overload Protection
- Built-in Electrical Limit Switches
- Position Feedback Available: Endstop Signal, Hall Sensor, Reed Switches
- Maximum Stroke: 1,000mm
- Protection Level: IP66
- Noise Level: ≤65 dB
- Color: Silver/Black
Specifications
| Code | Lead Screw | Duty Cycle | Max. Dynamic Load (N) | Max. Self Locking Load (N) | Pitch (mm) | No Load Speed (mm/s) +/-10% | Full Load Speed (mm/s) +/-10% | Max. Stroke (mm) |
|---|---|---|---|---|---|---|---|---|
| A | Ball Screw | 20% | 17,000 | 20,000 | 5 | 6.5 | 5 | 600 |
| B | 35% | 13,500 | 15,000 | 5 | 9 | 6.5 | 1,000 | |
| C | 10,000 | 12,000 | 5 | 14 | 9 | 1,000 | ||
| D | 7,500 | 10,000 | 10 | 18 | 13 | 1,000 | ||
| E | 5,000 | 8,000 | 10 | 28 | 20 | 1,000 | ||
| F | ACME Screw | 20% | 12,000 | 15,000 | 4 | 7 | 5 | 1,000 |
| G | 10,000 | 12,000 | 8 | 10 | 7 | 1,000 | ||
| H | 7,500 | 10,000 | 8 | 14 | 8 | 1,000 | ||
| I | 5,000 | 8,000 | 8 | 23 | 13 | 1,000 | ||
| J | 3,500 | 5,000 | 12 | 35 | 23 | 1,000 |
Dimensions
Unit: mm
Performance
