- Motor Voltage: 12V / 24V
- Load Capacity: 6,000N
- IP Rating: IP43
- Noise Level ≤45 dB
- Aluminum Shaft
- Worm Gearbox
- Electrical Limit Switch included
- Stroke Length: 50-600mm
- Cord Length: 500mm
- Operating Temperature Range: 5º – 40ºC (41º – 104ºF)
- Hall Sensor Available
- CE Certified
Specifications
| Code | Dynamic Load (N) | No Load Speed (mm/s) +/-10% | Full Load Speed (mm/s) +/-10% | 12V No Load Current (A) | 12V Full Load Current (A) | 24V No Load Current (A) | 24V Full Load Current (A) | Max. Stroke (mm) |
|---|---|---|---|---|---|---|---|---|
| A | 6,000 | 4.7 | 3.2 | 0.6 | 7.0 | 0.4 | 3.6 | 200 |
| B | 4,000 | 5.8 | 4.3 | 0.6 | 6.0 | 0.6 | 3.0 | 400 |
| C | 3,000 | 8.8 | 6.5 | 0.7 | 7.0 | 0.6 | 3.0 | 500 |
| D | 2,000 | 11.7 | 8.1 | 0.8 | 7.0 | 0.6 | 3.2 | 600 |
| E | 1,500 | 17.5 | 11.7 | 0.7 | 7.0 | 0.5 | 3.1 | 600 |
| F | 800 | 28 | 19.2 | 0.9 | 8.0 | 0.9 | 3.2 | 600 |
Dimensions
Formula:
L = Min. Mounting Length, S = Stroke Length
(S= 50mm – 450mm) L = S + 175mm
(S = 450 – 800mm) L = S + 200mm
Downloads
Catalog Download: MLA-28 Data Sheet.pdf
