General Environment Belt Module

Compatible Motor Size (AC): 750W
Synchronous Wheel Diameter: 47.75mm
Lead (mm): 150 / 75
Horizontal Max Payload (kg): 25 / 60
Vertical Max Payload (kg): 5 / 10
Repeatability: ± 0.05mm
Max Stroke: 5,700mm

Compatible Motor Size (AC): 400W
Synchronous Wheel Diameter: 56.02mm
Lead (mm): 188
Horizontal Max Payload (kg): 20/40
Vertical Max Payload (kg): N/A
Repeatability: ± 0.05mm
Max Stroke: 5,500mm

Compatible Motor Size (AC): 750W
Synchronous Wheel Diameter: 63.66mm
Lead (mm): 200
Horizontal Max Payload (kg): N/A
Vertical Max Payload (kg): 15
Repeatability: ± 0.05mm
Max Stroke: 2,000mm
