- Diameter: 36 mm
- Length: 40 mm
Description
| MODEL | V1 | V2 | V3 | |
|---|---|---|---|---|
| Voltage | Operating Range (V) | 8-16 | 8-26 | 8-26 |
| Rated (V) | 12 | 18 | 24 | |
| No Load | Speed (rpm) | 4769 | 7068 | 8235 |
| Current (A) | 0.16 | 0.19 | 0.184 | |
| Max. Efficiency | Speed (rpm) | 4006 | 6008 | 6835 |
| Current (A) | 0.818 | 1.071 | 1.186 | |
| Torque (g.cm) | 146.7 | 211.9 | 288.2 | |
| Output (W) | 6.028 | 130.055 | 20.205 | |
| Stall | Torque (g.cm) | 917 | 1412.4 | 1695.4 |
| Current (A) | 4.271 | 6.066 | 5.769 |
Speed Torque Curves
Drawing
