- Diameter: 36 mm
- Length: 30 mm
Description
| MODEL | V1 | V2 | V3 | |
|---|---|---|---|---|
| Voltage | Operating Range (V) | 8-16 | 8-26 | 8-26 |
| Rated (V) | 12 | 18 | 24 | |
| No Load | Speed (rpm) | 5817 | 7526 | 8872 |
| Current (A) | 0.249 | 0.209 | 0.184 | |
| Max. Efficiency | Speed (rpm) | 4882 | 6171 | 7364 |
| Current (A) | 0.638 | 0.957 | 0.872 | |
| Torque (g.cm) | 138.1 | 183.0 | 191.3 | |
| Output (W) | 6.507 | 11.584 | 14.451 | |
| Stall | Torque (g.cm) | 657.4 | 1016.8 | 1125.6 |
| Current (A) | 3.456 | 4.366 | 4.234 |
Speed Torque Curves
Drawing
