- 12 ~ 48VDC Motor
- Up to 2,500N Dynamic Load
- Thermistor Overload Protection
- Position Feedback Available: Endstop Signal, Hall Sensors
- Maximum Stroke: 600mm
- Protection Level: IP66
- Noise Level: ≤45 dB
- Color: Black
Specifications
| Code | Max. Dynamic Load (N) | Max. Self-locking Load (N) | Pitch (mm) | No Load Speed (mm/s) +/-10% | Full Load Speed (mm/s) +/-10% | Max. Stroke (mm) |
|---|---|---|---|---|---|---|
| A | 2,500 | 3,500 | 3.17 | 2.5 | 1.8 | 300 |
| B | 2,000 | 3,000 | 5 | 4.0 | 3.0 | 400 |
| C | 1,500 | 2,500 | 7.5 | 6.0 | 4.0 | 400 |
| D | 1,200 | 2,000 | 5 | 8.0 | 6.0 | 500 |
| E | 1,000 | 1,500 | 7.5 | 12.0 | 8.0 | 500 |
| F | 500 | 700 | 15 | 22.0 | 17.0 | 600 |
Dimensions
Unit: mm
Performance
Downloads
Catalog Download: MLA-J6 Data Sheet.pdf
