- 12 ~ 48VDC Motor
- Up to 900N Dynamic Load
- Position Feedback Available: Encoder, Potentiometer, Hall Sensor, Reed Switches
- Maximum Stroke: 1,016mm
- Protection Level: IP54 (IP65 Customizable)
- Noise Level: ≤55 dB
- Certifications: CE, RoHS
- Color: Silver, Black or Red
- Typical Lead Time: 4-6 Weeks
Specifications
| Model | Max. Dynamic Load (N) | No Load Speed (mm/s) | Full Load Speed (mm/s) | Duty Cycle (%) |
|---|---|---|---|---|
| MLA-AB-3 | 900 | 3 | 3 | 25 |
| MLA-AB-6 | 900 | 6 | 4 | |
| MLA-AB-10 | 750 | 10 | 7 | |
| MLA-AB-16 | 600 | 16 | 9 | |
| MLA-AB-20 | 450 | 20 | 14 | |
| MLA-AB-24 | 350 | 24 | 16 | |
| MLA-AB-29 | 300 | 29 | 21 | |
| MLA-AB-40 | 200 | 40 | 23 | |
| MLA-AB-50 | 150 | 50 | 30 | |
| MLA-AB-60 | 100 | 60 | 36 | |
| MLA-AB-80 | 20 | 80 | 50 | |
| MLA-S-6 | 400 | 6 | 5.2 | |
| MLA-S-10 | 350 | 10 | 8.5 | |
| MLA-S-16 | 300 | 16 | 13 | |
| MLA-S-20 | 250 | 20 | 17 | |
| MLA-S-24 | 200 | 24 | 20 | |
| MLA-S-29 | 150 | 29 | 24 |
Dimensions
Unit: Inches
Performance
Downloads
Catalog Download: MLA-AB Linear Actuator 2026 Catalog.pdf
3D Model Download: MLA-AB-50mm-Stroke 3D Model.zip
